                                       Advance Technical Information

TrenchMVTM                                    IXTF250N075T                                  VDSS           = 75    V
Power MOSFET                                                                                ID25           = 140   A
(Electrically Isolated Back Surface)                                                        RDS(on)           4.4 m
N-Channel Enhancement Mode
Avalanche Rated
                                                                                          ISOPLUS i4-PakTM (5-lead) (IXTF)




Symbol       Test Conditions                                    Maximum Ratings
VDSS         TJ = 25
