>> Download mje521-d documenatation <<Text preview - extract from the documentMJE521
Plastic Medium-Power
NPN Silicon Transistor
These devices are designed for use in general-purpose amplifier and
switching circuits. Recommended for use in 5 to 10 Watt audio
amplifiers utilizing complementary symmetry circuitry.
