Image preview - the first page of the document



>> Download dta143x documenatation <<

Text preview - extract from the document

                                                     DTA143XUA/DTA143XKA/DTA143XSA
                                                                DTA143XE/DTA143XCA
                                                                               Digital Transistor(PNP)

Features
1) Built-in bias resistors enable the configuration of an inverter circuit without
   connecting external input resistors (see equivalent circuit).
2) The bias resistors consist of thin-film resistors with complete isolation to
   allow negative biasing of the input. They also have the advantage
    of almost completely eliminating parasitic effects.
3) Only the on/off conditions need to be set for operation,
   making device design easy.


PIN CONNENCTIONS AND MARKING

 DTA143XE                                                   DTC114EUA
                                                            DTA143XUA




                                                            SOT-323

 SOT-523       Addreviated symbol: 33                                          Addreviated symbol: 33



 DTA143XKA                                                  DTA143XCA




                                                            SOT-23
 SOT-23-3L
                   Addreviated symbol: 33                                    Addreviated symbol: 33




 DTA143XSA




   TO-92S
                                                    DTA143XUA/DTA143XKA/DTA143XSA
                                                               DTA143XE/DTA143XCA
                                                                                 Digital Transistor(PNP)
Absolute maximum ratings (Ta=25)
                                                                Limits (DTA143X )
       Parameter          Symbol                                                                                 Unit
                                              E            UA            CA             KA         SA
 Supply voltage                 VCC                                      -50                                        V
 Input voltage                  VIN                                     -20~+7                                      V
                                 IO                                      -100
 Output current                                                                                                     mA
                           IC(MAX)                                       -100
 Power dissipation              Pd            150                        200                       300           mW
 Junction
                                 Tj                                      150
 temperature
 Storage temperature            Tstg                                 -55~150

Electrical characteristics (Ta=25)
 Parameter              Symbol         Min.         Typ          Max.            Unit               Conditions
                         VI(off)                                  -0.3                           VCC=-5V, IO=-100
