                                                  DTA114YE/DTA114YUA/DTA114YKA
                                                          DTA114YSA/DTA114YCA
                                                                          Digital Transistor(PNP)


Features
1.   Built-in bias resistors enable the configuration of an inverter circuit without
     connecting external input resistors(see equivalent circuit).
2.   The bias resistors consist of thin-film resistors with complete isolation to
     allow negative biasing of the input.They also have the advantage of almost
     completely eliminating parasitic effects.
3.   Only the on/off conditions need to be set for operation, making device
     design easy.



PIN CONNENCTIONS AND MARKING

 DTA114YE                                                   DTC114EUA
                                                            DTA114YUA




                                                            SOT-323

 SOT-523        Addreviated symbol: 54                                        Addreviated symbol: 54



 DTA114YKA                                                  DTA114YCA




                                                            SOT-23
 SOT-23-3L
                    Addreviated symbol: 54                                  Addreviated symbol: 54




 DTA114YSA




     TO-92S
                                                    DTA114YE/DTA114YUA/DTA114YKA
                                                            DTA114YSA/DTA114YCA
Absolute maximum ratings(Ta=25)
                                                                            Digital Transistor(PNP)

                                                                       Limits (DTA114Y )
                Parameter               Symbol                                                                       Unit
                                                          E     UA            KA           CA          SA
Supply voltage                            VCC                                 -50                                     V
Input voltage                             VIN                               -40to+6                                   V
                                           IO                                 -70                                    mA
Output current
                                         IC(Max.)                            -100                                    mA
Power dissipation                          PC         150                    200                       300           mW
Junction temperature                       Tj                                150

Storage temperature                       Tstg                            -55 to+ 150

Electrical characteristics (Ta=25)
     Parameter              Symbol     Min.         Typ       Max.          Unit                   Conditions
                             VI(off)                           -0.3                             VCC=-5V ,IO=-100
