Image preview - the first page of the document



>> Download dtc143e documenatation <<

Text preview - extract from the document

                                                        DTC143EE/DTC143EUA/DTC143ECA
                                                                DTC143EKA/DTC143ESA
                                                                               Digital Transistor(NPN)

Features
1) Built-in bias resistors enable the configuration of an inverter circuit without
   connecting external input resistors (see equivalent circuit).
2) The bias resistors consist of thin-film resistors with complete isolation to
   allow negative biasing of the input. They also have the advantage of
   almost completely eliminating parasitic effects.
3) Only the on/off conditions need to be set for operation, making
    device design easy.


PIN CONNENCTIONS AND MARKING

 DTC143EE                                                    DTC143EUA




   SOT-523          Addreviated symbol: 23                     SOT-323       Addreviated symbol: 23


                                                             DTA114ECA
                                                             DTC143ECA
 DTC143EKA



   SOT-23
 SOT-23-3L
                      Addreviated symbol: 23                 SOT-23
                                                                               Addreviated symbol: 23


 DTC143ESA




 TO-92S
                                                            DTC143EE/DTC143EUA/DTC143ECA
                                                                    DTC143EKA/DTC143ESA
                                                                                   Digital Transistor(NPN)
Absolute maximum ratings(Ta=25)
                                                                  Limits (DTC143E )
       Parameter           Symbol                                                                               Unit
                                                E            UA            KA             CA              SA
    Supply voltage                VCC                                      50                                    V
     Input voltage                VIN                                    -10~+30                                 V
                                   IO                                     100
    Output current                                                                                              mA
                               IC(MAX)                                    100
  Power dissipation               Pd            150                       200                             300   mW
Junction temperature               Tj                                     150
 Storage temperature              Tstg                                   -55~150
Electrical characteristics (Ta=25)
     Parameter         Symbol            Min.         Typ      Max.         Unit                Conditions
                        VI(off)                                   0.5                       VCC=5V ,IO=100
