Image preview - the first page of the document



>> Download dtc143x documenatation <<

Text preview - extract from the document

                                                        DTC143XE/DTC143XUA/DTC143XCA
                                                                DTC143XKA/DTC143XSA
                                                                               Digital Transistor(NPN)

Features
1) Built-in bias resistors enable the configuration of an inverter circuit without
   connecting external input resistors (see equivalent circuit).
2) The bias resistors consist of thin-film resistors with complete isolation to
   allow negative biasing of the input. They also have the advantage of
   almost completely eliminating parasitic effects.
3) Only the on/off conditions need to be set for operation, making device
   design easy.


PIN CONNENCTIONS AND MARKING

 DTC143XE                                                    DTC143XUA




   SOT-523          Addreviated symbol: 43                     SOT-323       Addreviated symbol: 43


                                                             DTA114ECA
                                                             DTC143XCA
 DTC143XKA




 SOT-23-3L
                      Addreviated symbol: 43                 SOT-23        Addreviated symbol: 43



 DTC143XSA




 TO-92S
                                                     DTC143XE/DTC143XUA/DTC143XCA
                                                             DTC143XKA/DTC143XSA
                                                                                Digital Transistor(NPN)
Absolute maximum ratings (Ta=25)
                                                               Limits (DTC143X )
       Parameter          Symbol                                                                                Unit
                                              E           UA            CA             KA         SA
 Supply voltage                 VCC                                     50                                        V
 Input voltage                  VIN                                    -7~+20                                     V
                                 IO                                     100
 Output current                                                                                                   mA
                           IC(MAX)                                      100
 Power dissipation              Pd            150                       200                       300             mW
 Junction
                                 Tj                                     150
 temperature
 Storage temperature            Tstg                                -55~150

Electrical characteristics (Ta=25)
 Parameter              Symbol         Min.         Typ         Max.            Unit               Conditions
                         VI(off)                                 0.3                            VCC=5V, IO=100
