Image preview - the first page of the document



>> Download dtc114w documenatation <<

Text preview - extract from the document

                                                     DTC114WE/DTC114WUA/DTC114WCA
                                                             DTC114WKA/DTC114WSA
                                                                            Digital Transistor(NPN)


Features
1) Built-in bias resistors enable the configuration of an inverter circuit without
   connecting external input resistors (see equivalent circuit).
2) The bias resistors consist of thin-film resistors with complete isolation to
   allow negative biasing of the input. They also have the advantage of
   almost completely eliminating parasitic effects.
3) Only the on/off conditions need to be set for operation, making
   device design easy.


PIN CONNENCTIONS AND MARKING

 DTC114WE                                                    DTC114WUA




   SOT-523          Addreviated symbol: 84                     SOT-323       Addreviated symbol: 84


                                                             DTA114ECA
                                                             DTC114WCA
 DTC114WKA


   SOT-23
 SOT-23-3L
                      Addreviated symbol: 84                 SOT-23        Addreviated symbol: 84



 DTC114WSA




 TO-92S
                                                  DTC114WE/DTC114WUA/DTC114WCA
                                                          DTC114WKA/DTC114WSA
                                                                             Digital Transistor(NPN)
Absolute maximum ratings (Ta=25)
                                                            Limits (DTC114W       )
     Parameter         Symbol                                                                                 Unit
                                           E           UA             CA              KA           SA
   Supply voltage          VCC                                        50                                       V
    Input voltage          VIN                                      -10~30                                     V
                               IO                                    100
   Output current                                                                                             mA
                         IC(MAX)                                     100
 Power dissipation         Pd             150                        200                           300        mW
      Junction
                               Tj                                    150
    temperature
Storage temperature       Tstg                                      -55~150

Electrical characteristics (Ta=25)
     Parameter         Symbol       Min.        Typ          Max.          Unit               Conditions
                        VI(off)                              0.8                           VCC=5V ,IO=100
