Image preview - the first page of the document



>> Download dtc123j documenatation <<

Text preview - extract from the document

                                                        DTC123JE/DTC123JUA/DTC123JCA
                                                                 DTC123JKA/DTC123JSA
                                                                                Digital Transistor(NPN)


Features
1) Built-in bias resistors enable the configuration of an inverter circuit
   without connecting external input resistors(see equivalent circuit).
2) The bias resistors consist of thin-film resistors with complete
   isolation to allow negative biasing of the input. They also have the
   advantage of almost completely eliminating parasitic effects.
3) Only the on/off conditions need to be set for operation, making
   device design easy.


PIN CONNENCTIONS AND MARKING

 DTC123JE                                                  DTC123JUA




   SOT-523       Addreviated symbol: E42                     SOT-323
                                                                             Addreviated symbol: E42


                                                           DTA114ECA
                                                           DTC123JCA
 DTC123JKA


   SOT-23
 SOT-23-3L

                   Addreviated symbol: E42                 SOT-23        Addreviated symbol: E42



 DTC123JSA




 TO-92S
                                                             DTC123JE/DTC123JUA/DTC123JCA
                                                                      DTC123JKA/DTC123JSA
                                                                                        Digital Transistor(NPN)
 Absolute maximum ratings(Ta=25)
                                                                  Limits (DTC123J          )
        Parameter           Symbol                                                                                     Unit
                                                 E           UA             KA                 CA              SA
 Supply voltage                    VCC                                      50                                          V
 Input voltage                     VIN                                     -5~12                                        V
                                   IO                                      100
 Output current                                                                                                        mA
                                IC(MAX)                                    100
 Power dissipation                 Pd            150                       200                                 300     mW
 Junction temperature              Tj                                      150
 Storage temperature             Tstg                                     -55~150

 Electrical characteristics (Ta=25)
     Parameter          Symbol            Min.         Typ         Max.          Unit                 Conditions
                         VI(off)                                   0.5                              VCC=5V, IO=100
