Image preview - the first page of the document
>> Download smg2321p documenatation <<Text preview - extract from the document SMG2321P
-4.1A , -20V , RDS(ON) 79 m
Elektronische Bauelemente P-Channel Enhancement MOSFET
RoHS Compliant Product
A suffix of "-C" specifies halogen & lead-free
SC-59
DESCRIPTION
The miniature surface mount MOSFETs utilize
A
high cell density process. Low RDS(on) assures minimal L
power loss and conserves energy, making this device 3
3
ideal for use in power management circuitry. Top View C B
1
1 2
K E 2
FEATURES
D
Low RDS(on) provides higher efficiency and extends
battery life. F G H J
Miniature SC-59 surface mount package saves
board space. Millimeter Millimeter
REF. REF.
Fast switching speed. Min. Max. Min. Max.
A 2.70 3.10 G 0.10 REF.
High performance trench technology. B 2.25 3.00 H 0.40 REF.
C 1.30 1.70 J 0.10 0.20
Low gate charge 7.2Nc. D 1.00 1.40 K 0.45 0.55
E 1.70 2.30 L 0.85 1.15
F 0.35 0.50
APPLICATION
DC-DC converters, power management in
portable and battery-powered products such as
computers, printers, PCMCIA cards, cellular and
cordless telephones.
PACKAGE INFORMATION
Package MPQ Leader Size
SC-59 3K 7' inch
ABSOLUTE MAXIMUM RATINGS (TA=25
