Image preview - the first page of the document



>> Download scg3019 documenatation <<

Text preview - extract from the document

                                                                                              SCG3019
                                                                                     N-Channel Enhancement MOSFET
                     Elektronische Bauelemente

                                                       RoHS Compliant Product
                                             A suffix of "-C" specifies halogen & lead-free
                                                                                                                   SOT-523



 FEATURES
           Low on-resistance.
           Fast switching speed.
           Low voltage drive makes this device ideal for portable equipment.
           Easily designed drive circuits.
           Easy to parallel.


 EQUIVALENT CIRCUIT
                                                                                                             Millimeter               Millimeter
                                                                                                    REF.                     REF.
                                                                                                            Min.   Max.              Min.   Max.
                                                                                                      A     1.50    1.70      K      0.30   0.50
                                                                                                                                                o
                                                                                                      B     0.75    0.95      M       ---    10
                                                                                                                                                o
                                                                                                      C     0.60    0.80      N       ---    10
                                                                                                      D     0.23    0.33      S      1.50   1.70
                                                                                                      G       0.50BSC
                                                                                                      J     0.10    0.20




   MAXIMUM RATINGS (TA=25 unless otherwise specified)

                              PARAMETER                                  SYMBOL               RATING                                 UNIT
       Drain-Source Voltage                                                 VDSS                  30                                    V

       Gate-Source Voltage                                                  VGSS
