Image preview - the first page of the document
>> Download ssd30n10-50d documenatation <<Text preview - extract from the document SSD30N10-50D
26A, 100V, RDS(ON) 50m
Elektronische Bauelemente N-Ch Enhancement Mode Power MOSFET
RoHS Compliant Product
A suffix of "-C" specifies halogen free
DESCRIPTION TO-252(D-Pack)
These miniature surface mount MOSFETs utilize a high
cell density trench process to provide low RDS(on) and to
ensure minimal power loss and heat dissipation.
FEATURES
Low RDS(on) provides higher efficiency and extends
battery life A
B C
Low thermal impedance copper leadframe TO-252 D
saves board space
Fast switching speed
High performance trench technology GE
APPLICATION K HF N
O
DC-DC converters and power management in portable P
M J
and battery-powered products such as computers, printers,
PCMCIA cards, cellular and cordless telephones. Millimeter Millimeter
REF. REF.
Min. Max. Min. Max.
A 6.4 6.8 J 2.30 REF.
B 5.20 5.50 K 0.70 0.90
PACKAGE INFORMATION C
D
2.20
0.45
2.40
0.58
M
N
0.50
0.9
1.1
1.6
E 6.8 7.3 O 0 0.15
Package MPQ LeaderSize F 2.40 3.0 P 0.43 0.58
G 5.40 6.2
H 0.8 1.20
TO-252 2.5K 13' inch
Drain
Gate
Source
ABSOLUTE MAXIMUM RATINGS (TA = 25
