Image preview - the first page of the document
>> Download ssd50p03-09d documenatation <<Text preview - extract from the document SSD50P03-09D
61A, -30V, RDS(ON) 9m
Elektronische Bauelemente P-Ch Enhancement Mode Power MOSFET
RoHS Compliant Product
A suffix of "-C" specifies halogen free
DESCRIPTION TO-252(D-Pack)
These miniature surface mount MOSFETs utilize high
cell density process. Low RDS(on) assures minimal power
loss and conserves energy, making this device ideal for
use in power management circuitry. Typical applications
are PWMDC-DC converters, power management in
portable and battery-powered products such as computers,
printers, battery charger, telecommunication power system,
and telephones power system. A
B C
D
FEATURES
Low RDS(on) provides higher efficiency and extends GE
battery life.
Miniature TO-252 surface mount package saves board K HF N
O
space. M J
P
High power and current handling capability.
Extended VGS range (
