Image preview - the first page of the document
>> Download ssp7436n documenatation <<Text preview - extract from the document SSP7436N
24 A, 30 V, RDS(ON) 4.6 m
Elektronische Bauelemente N-Channel Enhancement MOSFET
RoHS Compliant Product
A suffix of "-C" specifies halogen & lead-free
SOP-8PP
DESCRIPTION
B
These miniature surface mount MOSFETs utilize a high cell density trench process
to provide low RDS(on) and to ensure minimal power loss and heat dissipation.
Typical applications are DC-DC converters and power management in D
portable and battery-powered products such as computers, printers,
PCMCIA cards, cellular and cordless telephones. C
e E
FEATURES
Low RDS(on) provides higher efficiency and extends battery life. A
Low thermal impedance copper leadframe SOP-8PP saves board d b
space.
Fast switching speed. g
High performance trench technology.
F
G
Millimeter Millimeter
PRODUCT SUMMARY REF.
Min. Max.
REF.
Min. Max.
A 1.00 1.10 0
