                                                                                                                                                                    2N5469



  Dimensions in mm (inches).
                                                                                                                                       Bipolar NPN Device in a
                                                                                                                                      Hermetically sealed TO66
                                                                                                       6.35 (0.250)
                               3.68                                                                    8.64 (0.340)                        Metal Package.
                           (0.145) rad.                  3.61 (0.142)
                               max.                      4.08(0.161)
                                                             rad.



                                                                                                                                          Bipolar NPN Device.
                                                                         0.71 (0.028)
                                                                         0.86 (0.034)




                                           1      2




                                                                                                                      11.94 (0.470)
                                                                                                                      12.70 (0.500)
   24.13 (0.95)
   24.63 (0.97)




                                                                                                                                          VCEO = 400V
                  14.48 (0.570)
                  14.99 (0.590)




                                                                                                                                          IC = 3A

                                                                                                                                          All Semelab hermetically sealed products
                                                                                                                                          can be processed in accordance with the
                                                                                                                                          requirements of BS, CECC and JAN,
                                                                                                           1.27 (0.050)                   JANTX, JANTXV and JANS specifications
                                          4.83 (0.190)                                                     1.91 (0.750)
                                          5.33 (0.210)
                                                                                        9.14 (0.360)
                                                                                            min.



                                               TO66 (TO213AA)
                                                  PINOUTS
                   1
