Image preview - the first page of the document
>> Download 2n5151_2n5153 documenatation <<Text preview - extract from the document 2N5151
2N5153
MECHANICAL DATA
Dimensions in mm (inches) HIGH SPEED
8.89 (0.35)
9.40 (0.37) MEDIUM VOLTAGE
7.75 (0.305)
8.51 (0.335)
SWITCHES
4.19 (0.165)
4.95 (0.195)
DESCRIPTION
0.89 max.
(0.035)
12.70
(0.500)
7.75 (0.305)
The 2N5151 and the 2N5153 are silicon
min.
8.51 (0.335)
dia. expitaxial planar PNP transistors in
jedec TO-39 metal case intended for
5.08 (0.200)
use in switching applications.
typ.
The complementary NPN types are the
2.54
2N5152 and 2N5154 respectively
2 (0.100)
1 3
0.66 (0.026)
1.14 (0.045)
0.71 (0.028)
0.86 (0.034)
45
