Image preview - the first page of the document



>> Download 2n6425 documenatation <<

Text preview - extract from the document

                                                                                                                                                                     2N6425



  Dimensions in mm (inches).
                                                                                                                                       Bipolar PNP Device in a
                                                                                                                                      Hermetically sealed TO66
                                                                                                       6.35 (0.250)
                               3.68                                                                    8.64 (0.340)                        Metal Package.
                           (0.145) rad.                  3.61 (0.142)
                               max.                      4.08(0.161)
                                                             rad.



                                                                                                                                             Bipolar PNP Device.
                                                                         0.71 (0.028)
                                                                         0.86 (0.034)




                                           1      2




                                                                                                                      11.94 (0.470)
                                                                                                                      12.70 (0.500)
   24.13 (0.95)
   24.63 (0.97)




                                                                                                                                             VCEO = 300V
                  14.48 (0.570)
                  14.99 (0.590)




                                                                                                                                             IC = 0.25A

                                                                                                                                             All Semelab hermetically sealed products
                                                                                                                                             can be processed in accordance with the
                                                                                                                                             requirements of BS, CECC and JAN,
                                                                                                           1.27 (0.050)                      JANTX, JANTXV and JANS specifications
                                          4.83 (0.190)                                                     1.91 (0.750)
                                          5.33 (0.210)
                                                                                        9.14 (0.360)
                                                                                            min.



                                               TO66 (TO213AA)
                                                  PINOUTS
                   1
