                                                                                                                                                                        2N6537



  Dimensions in mm (inches).
                                                                                                                                       Bipolar NPN Device in a
                                                                                                                                      Hermetically sealed TO66
                                                                                                       6.35 (0.250)
                               3.68                                                                    8.64 (0.340)                        Metal Package.
                           (0.145) rad.                  3.61 (0.142)
                               max.                      4.08(0.161)
                                                             rad.



                                                                                                                                              Bipolar NPN Device.
                                                                         0.71 (0.028)
                                                                         0.86 (0.034)




                                           1      2




                                                                                                                      11.94 (0.470)
                                                                                                                      12.70 (0.500)
   24.13 (0.95)
   24.63 (0.97)




                                                                                                                                              VCEO = 120V
                  14.48 (0.570)
                  14.99 (0.590)




                                                                                                                                              IC = 8A

                                                                                                                                              All Semelab hermetically sealed products
                                                                                                                                              can be processed in accordance with the
                                                                                                                                              requirements of BS, CECC and JAN,
                                                                                                           1.27 (0.050)                       JANTX, JANTXV and JANS specifications
                                          4.83 (0.190)                                                     1.91 (0.750)
                                          5.33 (0.210)
                                                                                        9.14 (0.360)
                                                                                            min.



                                               TO66 (TO213AA)
