Image preview - the first page of the document



>> Download 2n6660 documenatation <<

Text preview - extract from the document

Supertex inc.                                                                                                                                         2N6660
                                                   N-Channel Enhancement-Mode
                                                   Vertical DMOS FET
Features                                                                                   General Description
     Free from secondary breakdown                                                         The Supertex 2N6660 is an enhancement-mode (normally-
     Low power drive requirement                                                           off) transistor that utilizes a vertical DMOS structure and
     Ease of paralleling                                                                   Supertex's well-proven silicon-gate manufacturing process.
     Low CISS and fast switching speeds                                                    This combination produces a device with the power handling
                                                                                           capabilities of bipolar transistors, and the high input
     Excellent thermal stability
                                                                                           impedance and positive temperature coefficient inherent
     Integral source-drain diode
                                                                                           in MOS devices. Characteristic of all MOS structures, this
     High input impedance and high gain
                                                                                           device is free from thermal runaway and thermally-induced
     Hi-Rel processing available                                                           secondary breakdown.
Applications                                                                               Supertex's vertical DMOS FETs are ideally suited to a wide
     Motor controls                                                                        range of switching and amplifying applications where very
     Converters                                                                            low threshold voltage, high breakdown voltage, high input
     Amplifiers                                                                            impedance, low input capacitance, and fast switching
     Switches                                                                              speeds are desired.
     Power supply circuits
     Drivers (relays, hammers, solenoids, lamps,
     memories, displays, bipolar transistors, etc.)

Ordering Information
                                                                                BVDSS/BVDGS                            RDS(ON)                        ID(ON)
            Device                             Package                                                                  (max)                         (min)
                                                                                          (V)
                                                                                                                         ()                            (A)

            2N6660                               TO-39                                    60                             3.0                          1.5
TO-39 package is RoHS compliant (`Green').
Consult factory for die / wafer form part numbers.
Refer to Die Specification VF21 for layout and dimensions.                                      Pin Configuration
Absolute Maximum Ratings
 Parameter                                                                  Value
                                                                                                                                         GATE
  Drain-to-source voltage                                                    BVDSS
                                                                                                                          SOURCE
  Drain-to-gate voltage                                                     BVDGS
                                                                                                                                             DRAIN
  Gate-to-source voltage
