Image preview - the first page of the document
bf1105_r_wr


>> Download bf1105_r_wr documenatation <<

Text preview - extract from the document
                   DISCRETE SEMICONDUCTORS




  DATA SHEET




  BF1105; BF1105R; BF1105WR
  N-channel dual-gate MOS-FETs
Product specification                        1997 Dec 02
Supersedes data of 1997 Dec 01
NXP Semiconductors                                                                                               Product specification

                                                                                              BF1105; BF1105R;
    N-channel dual-gate MOS-FETs
                                                                                                    BF1105WR

FEATURES                                   PINNING
 Short channel transistor with high              PIN              DESCRIPTION                       3
                                                                                      handbook, 2 columns                       4
 forward transfer admittance to input
                                                  1          source
 capacitance ratio
                                                  2          drain
 Low noise gain controlled amplifier
 up to 1 GHz.                                     3          gate 2
                                                                                                      2                         1
 Internal self-biasing circuit to                 4          gate 1
 ensure good cross-modulation                                                                         Top view              MSB035

 performance during AGC and good
 DC stabilization.                                                                        BF1105R marking code: NAp.



APPLICATIONS                                                                                  Fig.2           Simplified outline
                                                                                                              (SOT143R).
 VHF and UHF applications with 5 V
 supply voltage, such as television
 tuners and professional
 communications equipment.
                                                         4
                                            handbook, 2 columns            3        alfpage               3                 4

DESCRIPTION
Enhancement type N-channel
field-effect transistor with source and
                                                        1                  2                              2                 1
substrate interconnected. Integrated
diodes between gates and source                        Top view         MSB014                            Top view     MSB842

protect against excessive input
voltage surges. The BF1105,                    BF1105 marking code: NEp.                  BF1105WR marking code: NA.
BF1105R and BF1105WR are
encapsulated in the SOT143B,                      Fig.1      Simplified outline               Fig.3           Simplified outline
SOT143R and SOT343R plastic                                  (SOT143B).                                       (SOT343R).
packages respectively.

QUICK REFERENCE DATA

 SYMBOL                PARAMETER                                     CONDITIONS               MIN.             TYP.    MAX.          UNIT
VDS          drain-source voltage                                                                                      7             V
ID           drain current                                                                                             30            mA
Ptot         total power dissipation                  Tamb  80 C                                                       200           mW
yfs          forward transfer admittance                                                      25              31                     mS
Cig1-ss      input capacitance at gate 1                                                                      2.2      2.7           pF
Crss         reverse transfer capacitance             f = 1 MHz                                               25       40            fF
F            noise figure                             f = 800 MHz                                             1.7      2.5           dB
Xmod         cross-modulation                         input level for k = 1% at 40 dB AGC 100                                        dBV
Tj           operating junction temperature                                                                            150           C


                                                              CAUTION
 This product is supplied in anti-static packing to prevent damage caused by electrostatic discharge during transport
 and handling.



1997 Dec 02                                                       2
NXP Semiconductors                                                                                    Product specification


  N-channel dual-gate MOS-FETs                                                 BF1105; BF1105R; BF1105WR

LIMITING VALUES
In accordance with the Absolute Maximum Rating System (IEC 134).
 SYMBOL                      PARAMETER                                CONDITIONS               MIN.       MAX.       UNIT
VDS               drain-source voltage                                                                7          V
ID                drain current                                                                       30         mA
IG1               gate 1 current                                                                      10         mA
IG2               gate 2 current                                                                      10         mA
Ptot              total power dissipation                   Tamb  80 C; note 1; see Fig.4             200        mW
Tstg              storage temperature                                                       65        +150       C
Tj                operating junction temperature                                                      +150       C

Note
1. Device mounted on a printed-circuit board.




                                                   MGM243
        250
handbook, halfpage
       Ptot
      (mW)
        200



        150



        100



         50



          0
              0         40         80       120        160
                                               Tamb (
