Image preview - the first page of the document
bf1109_r_wr


>> Download bf1109_r_wr documenatation <<

Text preview - extract from the document
                   DISCRETE SEMICONDUCTORS




  DATA SHEET




  BF1109; BF1109R; BF1109WR
  N-channel dual-gate MOS-FETs
Product specification                        1997 Dec 08
Supersedes data of 1997 Sep 03
NXP Semiconductors                                                                                          Product specification

                                                                                              BF1109; BF1109R;
    N-channel dual-gate MOS-FETs
                                                                                                    BF1109WR

FEATURES                                   PINNING
 Short channel transistor with high             PIN               DESCRIPTION                        3
                                                                                       handbook, 2 columns                     4
 forward transfer admittance to input
                                                  1          source
 capacitance ratio
                                                  2          drain
 Low noise gain controlled amplifier
 up to 1 GHz                                      3          gate 2                                  2                         1
 Internal self-biasing circuit to                 4          gate 1
                                                                                                     Top view               MSB035
 ensure good cross-modulation
 performance during AGC and good
 DC stabilization.                                                                         BF1109R marking code: NBp.



APPLICATIONS                                                                                   Fig.2     Simplified outline
                                                                                                         (SOT143R).
 VHF and UHF applications with 9 V
 supply voltage, such as television
 tuners and professional
 communications equipment.
                                                         4
                                            handbook, 2 columns            3        ok, halfpage            3                  4
DESCRIPTION
Enhancement type N-channel
field-effect transistor with source and
substrate interconnected. Integrated                    1                  2
                                                                                                            2                  1
diodes between gates and source                        Top view         MSB014                              Top view         MSB842
protect against excessive input
voltage surges. The BF1109,                    BF1109 marking code: NFp.                   BF1109WR marking code: NB.
BF1109R and BF1109WR are
encapsulated in the SOT143B,                      Fig.1      Simplified outline                Fig.3     Simplified outline
SOT143R and SOT343R plastic                                  (SOT143B).                                  (SOT343R).
packages respectively.

QUICK REFERENCE DATA

 SYMBOL                PARAMETER                                     CONDITIONS               MIN.       TYP.          MAX.           UNIT
VDS          drain-source voltage                                                                                      11             V
ID           drain current (DC)                                                                                        30             mA
Ptot         total power dissipation                  Tamb  80 C                                                       200            mW
yfs          forward transfer admittance                                                                 30                           mS
Cig1-ss      input capacitance at gate 1                                                                 2.2           2.7            pF
Crss         reverse transfer capacitance             f = 1 MHz                                          25            40             fF
F            noise figure                             f = 800 MHz                                        1.5           2.5            dB
Xmod         cross-modulation                         input level for k = 1% at 40 dB AGC 100                                         dBV
Tj           operating junction temperature                                                                            150            C


                                                             CAUTION
 This product is supplied in anti-static packing to prevent damage caused by electrostatic discharge during transport
 and handling.



1997 Dec 08                                                       2
NXP Semiconductors                                                                                 Product specification


  N-channel dual-gate MOS-FETs                                                   BF1109; BF1109R; BF1109WR

LIMITING VALUES
In accordance with the Absolute Maximum Rating System (IEC 134).
 SYMBOL                      PARAMETER                               CONDITIONS             MIN.    MAX.         UNIT
VDS               drain-source voltage                                                             11        V
ID                drain current (DC)                                                               30        mA
IG1               gate 1 current                                                                   10        mA
IG2               gate 2 current                                                                   10        mA
Ptot              total power dissipation                   Tamb  80 C; note 1                     200       mW
Tstg              storage temperature                                                    65        +150      C
Tj                operating junction temperature                                                   +150      C

Note
1. Device mounted on a printed-circuit board.




                                                   MGM243
        250
handbook, halfpage
       Ptot
      (mW)
        200



        150



        100



         50



          0
              0         40         80       120        160
                                               Tamb (
