                   DISCRETE SEMICONDUCTORS




  DATA SHEET




  BF1202; BF1202R; BF1202WR
  N-channel dual-gate PoLo
  MOS-FETs
Product specification                        2010 Sep 16
Supersedes data of 2000 Mar 29
NXP Semiconductors                                                                                                Product specification


    N-channel dual-gate PoLo MOS-FETs                                              BF1202; BF1202R; BF1202WR

FEATURES                                   PINNING
 Short channel transistor with high                  PIN               DESCRIPTION                        3
                                                                                            handbook, 2 columns                     4
 forward transfer admittance to input
                                                       1               source
 capacitance ratio
                                                       2               drain
 Low noise gain controlled amplifier
                                                       3               gate 2
 Partly internal self-biasing circuit to                                                                     2                      1
 ensure good cross-modulation                          4               gate 1
 performance during AGC and good                                                                             Top view         MSB035

 DC stabilization.                         Marking code legend:
                                                                                                  BF1202R marking code: LE*
                                              * = - : made in Hong Kong
APPLICATIONS
                                              * = p : made in Hong Kong                           Fig.2        Simplified outline
 VHF and UHF applications with                * = t : made in Malaysia                                         (SOT143R).
 3 to 9 V supply voltage, such as
 digital and analogue television
 tuners and professional
 communications equipment.
                                                         4
                                            handbook, 2 columns                3         lfpage              3                4

DESCRIPTION
Enhancement type N-channel
field-effect transistor with source and                 1                      2                             2                1
substrate interconnected. Integrated
diodes between gates and source                        Top view           MSB014                             Top view      MSB842

protect against excessive input
voltage surges. The BF1202,                    BF1202 marking code: LD*                           BF1202WR marking code: LE*
BF1202R and BF1202WR are
encapsulated in the SOT143B,                   Fig.1        Simplified outline                    Fig.3        Simplified outline
SOT143R and SOT343R plastic                                 (SOT143B).                                         (SOT343R).
packages respectively.

QUICK REFERENCE DATA

 SYMBOL                  PARAMETER                                CONDITIONS                MIN.             TYP.          MAX.          UNIT
VDS          drain-source voltage                                                                                       10              V
ID           drain current                                                                                              30              mA
Ptot         total power dissipation                                                                                    200             mW
yfs          forward transfer admittance                                                 25               30            40              mS
Cig1-ss      input capacitance at gate 1                                                                  1.7           2.2             pF
Crss         reverse transfer capacitance              f = 1 MHz                                          15            30              fF
F            noise figure                              f = 800 MHz                                        1.1           1.8             dB
Xmod         cross-modulation                          input level for k = 1% at         100              105                           dBV
                                                       40 dB AGC
Tj           operating junction temperature                                                                             150             C


                                                              CAUTION
 This product is supplied in anti-static packing to prevent damage caused by electrostatic discharge during transport
 and handling.

2010 Sep 16                                                        2
NXP Semiconductors                                                                                         Product specification


  N-channel dual-gate PoLo MOS-FETs                                                   BF1202; BF1202R; BF1202WR

LIMITING VALUES
In accordance with the Absolute Maximum Rating System (IEC 60134).
 SYMBOL                          PARAMETER                                       CONDITIONS      MIN.       MAX.         UNIT
VDS                  drain-source voltage                                                                 10         V
ID                   drain current                                                                        30         mA
IG1                  gate 1 current                                                                       10         mA
IG2                  gate 2 current                                                                       10         mA
Ptot                 total power dissipation
                       BF1202; BF1202R                                    Ts  113 C; note 1               200        mW
                       BF1202WR                                           Ts  119 C; note 1               200        mW
Tstg                 storage temperature                                                      65          +150       C
Tj                   operating junction temperature                                                       150        C

Note
1. Ts is the temperature of the soldering point of the source lead.


THERMAL CHARACTERISTICS

 SYMBOL                                                   PARAMETER                                VALUE            UNIT
Rth j-s              thermal resistance from junction to soldering point
                       BF1202; BF1202R                                                              185              K/W
                       BF1202WR                                                                     155              K/W




                                                             MCD951
        250
handbook, halfpage
       Ptot
       (mW)
        200


                                        (2)   (1)
        150



        100



          50



          0
               0          50          100           150             200
                                                          Ts (
