Image preview - the first page of the document
bf1205


>> Download bf1205 documenatation <<

Text preview - extract from the document
                        DISCRETE SEMICONDUCTORS




  DATA SHEET
 handbook, halfpage




                          MBD128




   BF1205
   Dual N-channel dual gate
   MOS-FET
Product specification                             2003 Sep 30
NXP Semiconductors                                                                                           Product specification


  Dual N-channel dual gate MOS-FET                                                                                  BF1205

FEATURES                                                          PINNING - SOT363
 Two low noise gain controlled amplifiers in a single                         PIN                          DESCRIPTION
 package. One with a fully integrated bias and one with a
                                                                               1             gate 1 (a)
 partly integrated bias
                                                                               2             gate 2
 Internal switch reduces the number of external
 components                                                                    3             gate 1 (b)
 Superior cross-modulation performance during AGC                              4             drain (b)
 High forward transfer admittance                                              5             source

 High forward transfer admittance to input capacitance                         6             drain (a)
 ratio.


APPLICATIONS
                                                                  handbook, halfpage              d (a)       s      d (b)
 Gain controlled low noise amplifiers for VHF and UHF
 applications with 5 V supply voltage, such as digital and                6        5     4

 analog television tuners and professional
 communications equipment.
                                                                                                  AMP                AMP
                                                                                                   a                  b
DESCRIPTION
The BF1205 is a combination of two equal dual gate                        1        2     3
MOS-FET amplifiers with shared source and gate 2 leads                        Top view            g1 (a)      g2     g1 (b)
and an integrated switch. The integrated switch is                                                                            MGX429

operated by the gate 1 bias of amplifier b. The source and
substrate are interconnected. Internal bias circuits enable
DC stabilization and a very good cross-modulation                    Marking code: L4-.
performance during AGC. Integrated diodes between the
gates and source protect against excessive input voltage                           Fig.1 Simplified outline and symbol.
surges. The transistor is encapsulated in SOT363
micro-miniature plastic package.

ORDERING INFORMATION

                                                                     PACKAGE
  TYPE NUMBER
                          NAME                                    DESCRIPTION                                        VERSION
BF1205                                 Plastic surface mounted package; 6 leads                                       SOT363




2003 Sep 30                                                   2
NXP Semiconductors                                                                                  Product specification


  Dual N-channel dual gate MOS-FET                                                                        BF1205

QUICK REFERENCE DATA

 SYMBOL                   PARAMETER                               CONDITIONS               MIN. TYP. MAX. UNIT
Per MOS-FET; unless otherwise specified
VDS           drain-source voltage                                                                        10       V
ID            drain current (DC)                                                                          30       mA
Ptot          total power dissipation                 Ts  102 C; temperature at the                       200      mW
                                                      soldering point of the source lead
yfs           forward transfer admittance             ID = 12 mA                           26      31     40       mS
Cig1-ss       input capacitance at gate 1             amp. a: f = 1 MHz                            1.8    2.3      pF
                                                      amp. b: f = 1 MHz                            2.0    2.5      pF
Crss          reverse transfer capacitance            f = 1 MHz                                    20              fF
NF            noise figure                            amp. a: f = 800 MHz                          1.2    1.9      dB
                                                      amp. b: f = 800 MHz                          1.4    2.1      dB
Xmod          cross-modulation                        amp. a: input level for k = 1% at    98      102             dBV
                                                      40 dB AGC
                                                      amp. b: input level for k = 1% at    100     105             dBV
                                                      40 dB AGC
Tj            junction temperature                                                                        150      C


                                                       CAUTION
 This product is supplied in anti-static packing to prevent damage caused by electrostatic discharge during transport
 and handling.


LIMITING VALUES
In accordance with the Absolute Maximum Rating System (IEC 60134).
 SYMBOL                   PARAMETER                                 CONDITIONS                   MIN.    MAX.      UNIT
Per MOS-FET; unless otherwise specified
VDS           drain-source voltage                                                                       10        V
ID            drain current (DC)                                                                         30        mA
IG1           gate 1 current                                                                             10        mA
IG2           gate 2 current                                                                             10        mA
Ptot          total power dissipation                Ts  102 C; note                                     200       mW
Tstg          storage temperature                                                             65         +150      C
Tj            junction temperature                                                                       150       C

Note
1. Ts is the temperature at the soldering point of the source lead.


THERMAL CHARACTERISTICS

 SYMBOL                                     PARAMETER                                      VALUE                UNIT
Rth j-s       thermal resistance from junction to soldering point                           240                 K/W



2003 Sep 30                                                3
NXP Semiconductors                                                                                               Product specification


  Dual N-channel dual gate MOS-FET                                                                                       BF1205



                                                     MGS359
       250
handbook, halfpage
      Ptot
     (mW)
        200



        150



        100



         50



          0
              0           50       100      150             200
                                                  Ts (
