Image preview - the first page of the document
bfr93aw


>> Download bfr93aw documenatation <<

Text preview - extract from the document
                   DISCRETE SEMICONDUCTORS




  DATA SHEET




  BFR93AW
  NPN 5 GHz wideband transistor
Product specification                        1995 Sep 18
Supersedes data of November 1992
NXP Semiconductors                                                                                       Product specification


     NPN 5 GHz wideband transistor                                                                            BFR93AW

FEATURES                                   DESCRIPTION
                                                                                                              3
 High power gain                           Silicon NPN transistor encapsulated     handbook, 2 columns

 Gold metallization ensures                in a plastic SOT323 (S-mini) package.
 excellent reliability                     The BFR93AW uses the same crystal
                                           as the SOT23 version, BFR93A.
 SOT323 (S-mini) package.

                                           PINNING
APPLICATIONS                                                                                              1          2
                                              PIN            DESCRIPTION
It is designed for use in RF amplifiers,                                                      Top view             MBC870
mixers and oscillators with signal             1      base                             Marking code: R2.
frequencies up to 1 GHz.                       2      emitter
                                                                                                  Fig.1 SOT323
                                               3      collector


QUICK REFERENCE DATA

 SYMBOL             PARAMETER                             CONDITIONS                   MIN.         TYP.      MAX.          UNIT
VCBO         collector-base voltage        open emitter                                                       15            V
VCEO         collector-emitter voltage     open base                                                          12            V
IC           collector current (DC)                                                                           35            mA
Ptot         total power dissipation       up to Ts = 93 C; note 1                                            300           mW
hFE          DC current gain               IC = 30 mA; VCE = 5 V                   40           90
Cre          feedback capacitance          IC = 0; VCE = 5 V; f = 1 MHz;                        0.6                         pF
                                           Tamb = 25 C
fT           transition frequency          IC = 30 mA; VCE = 5 V; f = 500 MHz      4            5                           GHz
GUM          maximum unilateral power      IC = 30 mA; VCE = 8 V; f = 1 GHz;                    13                          dB
             gain                          Tamb = 25 C
                                           IC = 30 mA; VCE = 8 V; f = 2 GHz;                    8                           dB
                                           Tamb = 25 C
F            noise figure                  IC = 5 mA; VCE = 8 V; f = 1 GHz;                     1.5                         dB
                                           s = opt
Tj           junction temperature                                                                             150           C

Note
1. Ts is the temperature at the soldering point of the collector pin.




1995 Sep 18                                                     2
NXP Semiconductors                                                                                                Product specification


  NPN 5 GHz wideband transistor                                                                                     BFR93AW

LIMITING VALUES
In accordance with the Absolute Maximum Rating System (IEC 134).
 SYMBOL                            PARAMETER                                        CONDITION                MIN.      MAX.     UNIT
VCBO                  collector-base voltage                            open emitter                                   15      V
VCEO                  collector-emitter voltage                         open base                                      12      V
VEBO                  emitter-base voltage                              open collector                                 2       V
IC                    collector current (DC)                                                                           35      mA
Ptot                  total power dissipation                           up to Ts = 93 C; see Fig.2; note 1             300     mW
Tstg                  storage temperature                                                                    65        +150    C
Tj                    junction temperature                                                                             150     C


THERMAL CHARACTERISTICS

 SYMBOL                            PARAMETER                                        CONDITION                   VALUE         UNIT
Rth j-s               thermal resistance from junction to               up to Ts = 93 C; note 1                  190          K/W
                      soldering point

Note to the Limiting values and Thermal characteristics
1. Ts is the temperature at the soldering point of the collector pin.




                                                           MLB540
          400

      P tot
     (mW)
          300




          200




          100




              0
                  0         50        100         150             200
                                                        T s ( o C)




                        Fig.2 Power derating curve.




1995 Sep 18                                                                3
NXP Semiconductors                                                                                                        Product specification


      NPN 5 GHz wideband transistor                                                                                          BFR93AW

CHARACTERISTICS
Tj = 25 C (unless otherwise specified).

 SYMBOL                   PARAMETER                                CONDITIONS                         MIN.         TYP.       MAX.        UNIT
 ICBO          collector leakage current                IE = 0; VCB = 5 V                                                  50           nA
 hFE           DC current gain                          IC = 30 mA; VCE = 5 V                     40           90
 Cc            collector capacitance                    IE = ie = 0; VCB = 5 V; f = 1 MHz                      0.7                      pF
 Ce            emitter capacitance                      IC = ic = 0; VEB = 0.5 V;                              2.3                      pF
                                                        f = 1 MHz
 Cre           feedback capacitance                     IC = 0; VCE = 5 V; f = 1 MHz                           0.6                      pF
 fT            transition frequency                     IC = 30 mA; VCE = 5 V;                    4            5                        GHz
                                                        f = 500 MHz
 GUM           maximum unilateral power                 IC = 30 mA; VCE = 8 V;                                 13                       dB
               gain; note 1                             f = 1 GHz; Tamb = 25 C
                                                        IC = 30 mA; VCE = 8 V;                                 8                        dB
                                                        f = 2 GHz; Tamb = 25 C
 F             noise figure                             IC = 5 mA; VCE = 8 V;                                  1.5                      dB
                                                        f = 1 GHz; s = opt
                                                        IC = 5 mA; VCE = 8 V;                                  2.1                      dB
                                                        f = 2 GHz; s = opt

Note
                                                                                                           s 21 2
1. GUM is the maximum unilateral power gain, assuming s12 is zero and G UM = 10 log -------------------------------------------------------- dB.
