Image preview - the first page of the document
bfs540


>> Download bfs540 documenatation <<

Text preview - extract from the document
                   DISCRETE SEMICONDUCTORS




  DATA SHEET

 dbook, halfpage




                      M3D102




    BFS540
    NPN 9 GHz wideband transistor
Product specification                        2000 May 30
Supersedes data of 1997 Dec 05
NXP Semiconductors                                                                                       Product specification


     NPN 9 GHz wideband transistor                                                                                       BFS540

FEATURES                                  DESCRIPTION
 High power gain                          NPN transistor in a SOT323 plastic
 Low noise figure                         package.
                                                                                       handbook, 2 columns           3
 High transition frequency
 Gold metallization ensures               PINNING
 excellent reliability                       PIN            DESCRIPTION
 SOT323 package.                              1      base                                                        1          2

                                              2      emitter                                       Top view               MBC870

APPLICATIONS                                  3      collector
RF wideband amplifier applications                                                        Marking code: N4.
such as satellite TV systems and RF
portable communication equipment                                                                     Fig.1 SOT323.
with signal frequencies up to 2 GHz.


QUICK REFERENCE DATA

 SYMBOL                 PARAMETER                                  CONDITIONS                   MIN.         TYP.        MAX.      UNIT
VCBO          collector-base voltage               open emitter                                                          20        V
VCEO          collector-emitter voltage            open base                                                             15        V
IC            DC collector current                                                                                       120       mA
Ptot          total power dissipation              Ts  80 C; note 1                                                      500       mW
hFE           DC current gain                      IC = 40 mA; VCE = 8 V; Tj = 25 C             100          120         250
fT            transition frequency                 IC = 40 mA; VCE = 8 V; f = 1 GHz;                         9                     GHz
                                                   Tamb = 25 C
GUM           maximum unilateral power gain        IC = 40 mA; VCE = 8 V; f = 900 MHz;                       14                    dB
                                                   Tamb = 25 C
F             noise figure                         IC = 10 mA; VCE = 8 V; f = 900 MHz;                       1.3         1.7       dB
                                                   Tamb = 25 C

Note
1. Ts is the temperature at the soldering point of the collector tab.


LIMITING VALUES
In accordance with the Absolute Maximum System (IEC 60134).
 SYMBOL                      PARAMETER                               CONDITIONS                        MIN.          MAX.          UNIT
VCBO          collector-base voltage                  open emitter                                                   20            V
VCES          collector-emitter voltage               RBE = 0                                                        15            V
VEBO          emitter-base voltage                    open collector                                                 2.5           V
IC            DC collector current                                                                                   120           mA
Ptot          total power dissipation                 Ts  80 C; note 1                                               500           mW
Tstg          storage temperature                                                                     65             150           C
Tj            junction temperature                                                                                   175           C

Note
1. Ts is the temperature at the soldering point of the collector tab.

2000 May 30                                                    2
NXP Semiconductors                                                                                                                    Product specification


     NPN 9 GHz wideband transistor                                                                                                           BFS540

THERMAL CHARACTERISTICS

  SYMBOL                                                PARAMETER                                             CONDITIONS          VALUE             UNIT
Rth j-s                thermal resistance from junction to soldering point                             Ts  80 C; note 1                190          K/W

Note
1. Ts is the temperature at the soldering point of the collector tab.


CHARACTERISTICS
Tj = 25 C unless otherwise specified.

  SYMBOL                              PARAMETER                                                    CONDITIONS              MIN.   TYP.       MAX.    UNIT
ICBO                   collector cut-off current                                   IE = 0; VCE = 8 V                                         50     nA
hFE                    DC current gain                                             IC = 40 mA; VCE = 8 V                   100    120        250
Ce                     emitter capacitance                                         IC = ic = 0; VEB = 0.5 V; f = 1 MHz            2                 pF
Cc                     collector capacitance                                       IE = ie = 0; VCB = 8 V; f = 1 MHz              0.9               pF
Cre                    feedback capacitance                                        IC = 0; VCB = 8 V; f = 1 MHz                   0.6               pF
fT                     transition frequency                                        IC = 40 mA; VCE = 8 V; f = 1 GHz;              9                 GHz
                                                                                   Tamb = 25 C
GUM                    maximum unilateral power                                    IC = 40 mA; VCE = 8 V; f = 900 MHz;            14                dB
                       gain (note 1)                                               Tamb = 25 C
                                                                                   IC = 40 mA; VCE = 8 V; f = 2 GHz;              8                 dB
                                                                                   Tamb = 25 C
s212                   insertion power gain                                        IC = 40 mA; VCE = 8 V; f = 900 MHz;     12     13                dB
                                                                                   Tamb = 25 C
F                      noise figure                                                s = opt; IC = 10 mA; VCE = 8 V;                1.3        1.8    dB
                                                                                   f = 900 MHz; Tamb = 25 C
                                                                                   s = opt; IC = 40 mA; VCE = 8 V;                1.9        2.4    dB
                                                                                   f = 900 MHz; Tamb = 25 C
                                                                                   s = opt; IC = 10 mA; VCE = 8 V;                2.1               dB
                                                                                   f = 2 GHz; Tamb = 25 C
PL1                    output power at 1 dB gain                                   Ic = 40 mA; VCE = 8 V; RL = 50 ;               21                dBm
                       compression                                                 f = 900 MHz; Tamb = 25 C
ITO                    third order intercept point                                 note 2                                         34                dBm

Notes
1. GUM is the maximum unilateral power gain, assuming s12 is zero and
                                                        2
                                            s 21
       G UM = 10 log ------------------------------------------------------- dB.
                                            2                            2
                                                                           -
                      1
