Image preview - the first page of the document
bfs17w


>> Download bfs17w documenatation <<

Text preview - extract from the document
                   DISCRETE SEMICONDUCTORS




  DATA SHEET




  BFS17W
  NPN 1 GHz wideband transistor
Product specification                        1995 Sep 04
Supersedes data of November 1992
NXP Semiconductors                                                                                   Product specification


     NPN 1 GHz wideband transistor                                                                           BFS17W

APPLICATIONS                              PINNING
Primarily intended as a mixer,               PIN            DESCRIPTION                                   3
                                                                               handbook, 2 columns
oscillator and IF amplifier in UHF and
                                               1     base
VHF tuners.
                                               2     emitter
                                               3     collector
DESCRIPTION
                                                                                                      1           2
Silicon NPN transistor in a plastic                                                       Top view              MBC870
SOT323 (S-mini) package. The
BFS17W uses the same crystal as
the SOT23 version, BFS17.                                                       Marking code: E1

                                                                                             Fig.1 SOT323



QUICK REFERENCE DATA

 SYMBOL              PARAMETER                           CONDITIONS               MIN.         TYP.       MAX.           UNIT
VCBO          collector-base voltage                                                                      25             V
VCEO          collector-emitter voltage                                                                   15             V
IC            DC collector current                                                                        50             mA
Ptot          total power dissipation        up to Ts = 118 C; note 1                                     300            mW
hFE           DC current gain                IC = 2 mA; VCE = 1 V              25           90
fT            transition frequency           IC = 25 mA; VCE = 5 V                          1.6                          GHz
Cc            collector capacitance          IE = 0; VCB = 10 V; f = 1 MHz                  0.8           1.5            pF
Cre           feedback capacitance           IC = 1 mA; VCE = 5 V; f = 1 MHz                0.75                         pF
Tj            junction temperature                                                                        175            C

Note
1. Ts is the temperature at the soldering point of the collector pin.


LIMITING VALUES
In accordance with the Absolute Maximum Rating System (IEC 134).
 SYMBOL              PARAMETER                                 CONDITIONS                      MIN.       MAX.           UNIT
VCBO          collector-base voltage         open emitter                                                 25             V
VCEO          collector-emitter voltage      open base                                                    15             V
VEBO          emitter-base voltage           open collector                                               2.5            V
IC            collector current (DC)                                                                      50             mA
Ptot          total power dissipation        Ts = 118 C; note 1                                           300            mW
Tstg          storage temperature                                                           65            +150           C
Tj            junction temperature                                                                        175            C

Note
1. Ts is the temperature at the soldering point of the collector pin.




1995 Sep 04                                                    2
NXP Semiconductors                                                                                                                   Product specification


     NPN 1 GHz wideband transistor                                                                                                          BFS17W

THERMAL CHARACTERISTICS

 SYMBOL                                      PARAMETER                                                CONDITIONS                      VALUE            UNIT
Rth j-s               thermal resistance from junction to soldering point             up to Ts = 118 C; note 1                           190           K/W

Note
1. Ts is the temperature at the soldering point of the collector pin.


CHARACTERISTICS
Tj = 25 C (unless otherwise specified).

 SYMBOL                          PARAMETER                              CONDITIONS                           MIN.        TYP.            MAX.          UNIT
ICBO                  collector cut-off current                 IE = 0; VCB = 10 V                                                    10             nA
hFE                   DC current gain                           IC = 2 mA; VCE = 1 V                      25         90
fT                    transition frequency                      IC = 25 mA; VCE = 5 V;                               1.6                             GHz
                                                                f = 500 MHz
Cc                    collector capacitance                     IE = ie = 0; VCB = 10 V;                             0.8              1.5            pF
                                                                f = 1 MHz
Ce                    emitter capacitance                       IC = ic = 0; VEB = 0.5 V;                            2                               pF
                                                                f = 1 MHz
Cre                   feedback capacitance                      IB = ib = 0; VCE = 5 V;                              0.75                            pF
                                                                f = 1 MHz; Tamb = 25 C
F                     noise figure                              IC = 2 mA; VCE = 5 V;                                4.5                             dB
                                                                f = 500 MHz; S = opt



                                                           MLB587                                                                           MBG237
          400                                                                            60
handbook, halfpage                                                              handbook, halfpage
      P tot
     (mW)                                                                             hFE

          300
                                                                                         40



          200


                                                                                         20

          100




                                                                                          0
              0                                                                               10-1             1                10               102
                  0         50         100        150             200                                                                  IC (mA)
                                                        T s ( o C)



                                                                                   VCE = 1 V.


                                                                                      Fig.3          DC current gain as a function of collector
                        Fig.2 Power derating curve.                                                  current; typical values.



1995 Sep 04                                                                 3
NXP Semiconductors                                                                                                    Product specification


  NPN 1 GHz wideband transistor                                                                                              BFS17W



                                                            MBG238                                                               MBG239
            2                                                                     2.5
                                                                          handbook, halfpage
handbook, halfpage
     Cre
     (pF)                                                                       fT
                                                                              (GHz)
        1.5
                                                                                    2

                                                                                                                        VCE = 10 V
            1

                                                                                                                        5V
                                                                                   1.5
        0.5




            0                                                                       1
                0         2           4       6        8         10                      1                   10                      102
                                                           VCB (V)                                                     IC (mA)




   IB = ib = 0; f = 1 MHz.                                                   Tamb = 25 C; f = 500 MHz.


       Fig.4           Feedback capacitance as a function of                       Fig.5       Transition frequency as a function
                       collector-base voltage; typical values.                                 of collector current; typical values.




                                                            MBG240
         20
handbook, halfpage
        F
      (dB)

         15




         10




            5




            0
                10-3    10-2   10-1       1       10   102     103
                                                         f (MHz)




   VCE = 10 V.


       Fig.6           Minimum noise figure as function of
                       frequency; typical values.


1995 Sep 04                                                           4
NXP Semiconductors                                                                                                                        Product specification


  NPN 1 GHz wideband transistor                                                                                                                  BFS17W

PACKAGE OUTLINE
  Plastic surface-mounted package; 3 leads                                                                                                             SOT323




                                                D                         B                                      E                A          X




                             y                                                                                   HE                          v M A




                                                     3


                                                                                                                                   Q



                                                                                               A


                                                                                                     A1
                                                                                                                                      c
                         1                                      2

                                       e1           bp                                                                      Lp
                                                                     w M B

                                                e                                                                    detail X




                                                             0                       1                    2 mm

                                                                                 scale



   DIMENSIONS (mm are the original dimensions)
                   A1
     UNIT     A              bp             c       D       E        e         e1        HE        Lp      Q     v         w
                   max
             1.1             0.4        0.25        2.2    1.35                          2.2       0.45   0.23
     mm            0.1                                              1.3       0.65                               0.2       0.2
             0.8             0.3        0.10        1.8    1.15                          2.0       0.15   0.13




        OUTLINE                                                   REFERENCES                                                EUROPEAN
                                                                                                                                             ISSUE DATE
        VERSION                  IEC                      JEDEC                  JEITA                                     PROJECTION

                                                                                                                                                 04-11-04
          SOT323                                                                 SC-70
                                                                                                                                                 06-03-16




1995 Sep 04                                                                          5
NXP Semiconductors                                                                                          Product specification


  NPN 1 GHz wideband transistor                                                                                  BFS17W

DATA SHEET STATUS

        DOCUMENT               PRODUCT
                                                                                  DEFINITION
         STATUS(1)             STATUS(2)
Objective data sheet         Development      This document contains data from the objective specification for product
                                              development.
Preliminary data sheet       Qualification    This document contains data from the preliminary specification.
Product data sheet           Production       This document contains the product specification.

Notes
1. Please consult the most recently issued document before initiating or completing a design.
2. The product status of device(s) described in this document may have changed since this document was published
   and may differ in case of multiple devices. The latest product status information is available on the Internet at
   URL http://www.nxp.com.


DEFINITIONS                                                        Right to make changes  NXP Semiconductors
                                                                   reserves the right to make changes to information
Product specification  The information and data
                                                                   published in this document, including without limitation
provided in a Product data sheet shall define the
                                                                   specifications and product descriptions, at any time and
specification of the product as agreed between NXP
                                                                   without notice. This document supersedes and replaces all
Semiconductors and its customer, unless NXP
                                                                   information supplied prior to the publication hereof.
Semiconductors and customer have explicitly agreed
otherwise in writing. In no event however, shall an                Suitability for use  NXP Semiconductors products are
agreement be valid in which the NXP Semiconductors                 not designed, authorized or warranted to be suitable for
product is deemed to offer functions and qualities beyond          use in life support, life-critical or safety-critical systems or
those described in the Product data sheet.                         equipment, nor in applications where failure or malfunction
                                                                   of an NXP Semiconductors product can reasonably be
                                                                   expected to result in personal injury, death or severe
DISCLAIMERS
                                                                   property or environmental damage. NXP Semiconductors
Limited warranty and liability  Information in this                accepts no liability for inclusion and/or use of NXP
document is believed to be accurate and reliable.                  Semiconductors products in such equipment or
However, NXP Semiconductors does not give any                      applications and therefore such inclusion and/or use is at
representations or warranties, expressed or implied, as to         the customer's own risk.
the accuracy or completeness of such information and
                                                                   Applications  Applications that are described herein for
shall have no liability for the consequences of use of such
                                                                   any of these products are for illustrative purposes only.
information.
                                                                   NXP Semiconductors makes no representation or
In no event shall NXP Semiconductors be liable for any             warranty that such applications will be suitable for the
indirect, incidental, punitive, special or consequential           specified use without further testing or modification.
damages (including - without limitation - lost profits, lost
                                                                   Customers are responsible for the design and operation of
savings, business interruption, costs related to the
                                                                   their applications and products using NXP
removal or replacement of any products or rework
                                                                   Semiconductors products, and NXP Semiconductors
charges) whether or not such damages are based on tort
                                                                   accepts no liability for any assistance with applications or
(including negligence), warranty, breach of contract or any
                                                                   customer product design. It is customer's sole
other legal theory.
                                                                   responsibility to determine whether the NXP
Notwithstanding any damages that customer might incur              Semiconductors product is suitable and fit for the
for any reason whatsoever, NXP Semiconductors'                     customer's applications and products planned, as well as
aggregate and cumulative liability towards customer for            for the planned application and use of customer's third
the products described herein shall be limited in                  party customer(s). Customers should provide appropriate
accordance with the Terms and conditions of commercial             design and operating safeguards to minimize the risks
sale of NXP Semiconductors.                                        associated with their applications and products.



1995 Sep 04                                                    6
NXP Semiconductors                                                                                       Product specification


  NPN 1 GHz wideband transistor                                                                               BFS17W

NXP Semiconductors does not accept any liability related           Export control  This document as well as the item(s)
to any default, damage, costs or problem which is based            described herein may be subject to export control
on any weakness or default in the customer's applications          regulations. Export might require a prior authorization from
or products, or the application or use by customer's third         national authorities.
party customer(s). Customer is responsible for doing all
                                                                   Quick reference data  The Quick reference data is an
necessary testing for the customer's applications and
                                                                   extract of the product data given in the Limiting values and
products using NXP Semiconductors products in order to
                                                                   Characteristics sections of this document, and as such is
avoid a default of the applications and the products or of
                                                                   not complete, exhaustive or legally binding.
the application or use by customer's third party
customer(s). NXP does not accept any liability in this             Non-automotive qualified products  Unless this data
respect.                                                           sheet expressly states that this specific NXP
                                                                   Semiconductors product is automotive qualified, the
Limiting values  Stress above one or more limiting
                                                                   product is not suitable for automotive use. It is neither
values (as defined in the Absolute Maximum Ratings
                                                                   qualified nor tested in accordance with automotive testing
System of IEC 60134) will cause permanent damage to
                                                                   or application requirements. NXP Semiconductors accepts
the device. Limiting values are stress ratings only and
                                                                   no liability for inclusion and/or use of non-automotive
(proper) operation of the device at these or any other
                                                                   qualified products in automotive equipment or
conditions above those given in the Recommended
                                                                   applications.
operating conditions section (if present) or the
Characteristics sections of this document is not warranted.        In the event that customer uses the product for design-in
Constant or repeated exposure to limiting values will              and use in automotive applications to automotive
permanently and irreversibly affect the quality and                specifications and standards, customer (a) shall use the
reliability of the device.                                         product without NXP Semiconductors' warranty of the
                                                                   product for such automotive applications, use and
Terms and conditions of commercial sale  NXP
                                                                   specifications, and (b) whenever customer uses the
Semiconductors products are sold subject to the general
                                                                   product for automotive applications beyond NXP
terms and conditions of commercial sale, as published at
                                                                   Semiconductors' specifications such use shall be solely at
http://www.nxp.com/profile/terms, unless otherwise
                                                                   customer's own risk, and (c) customer fully indemnifies
agreed in a valid written individual agreement. In case an
                                                                   NXP Semiconductors for any liability, damages or failed
individual agreement is concluded only the terms and
                                                                   product claims resulting from customer design and use of
conditions of the respective agreement shall apply. NXP
                                                                   the product for automotive applications beyond NXP
Semiconductors hereby expressly objects to applying the
                                                                   Semiconductors' standard warranty and NXP
customer's general terms and conditions with regard to the
                                                                   Semiconductors' product specifications.
purchase of NXP Semiconductors products by customer.
No offer to sell or license  Nothing in this document
may be interpreted or construed as an offer to sell products
that is open for acceptance or the grant, conveyance or
implication of any license under any copyrights, patents or
other industrial or intellectual property rights.




1995 Sep 04                                                    7
  NXP Semiconductors
       provides High Performance Mixed Signal and Standard Product
       solutions that leverage its leading RF, Analog, Power Management,
       Interface, Security and Digital Processing expertise




      Customer notification

      This data sheet was changed to reflect the new company name NXP Semiconductors, including new legal
      definitions and disclaimers. No changes were made to the technical content, except for package outline
      drawings which were updated to the latest version.


      Contact information

      For additional information please visit: http://www.nxp.com
      For sales offices addresses send e-mail to: [email protected]








◦ Jabse Service Manual Search 2026 ◦ Jabse PravopisonTap.bg ◦ Other service manual resources online : FixyaeServiceinfo
