                                       BUK95/9610-100B
                                       TrenchMOSTM logic level FET
                                       Rev. 02 -- 8 October 2002                                                     Product data



1. Product profile

                           1.1 Description
                                  N-channel enhancement mode field-effect power transistor in a plastic package using
                                  Philips High-Performance Automotive TrenchMOSTM technology.

                                  Product availability:

                                       BUK9510-100B in SOT78 (TO-220AB)
                                       BUK9610-100B in SOT404 (D2-PAK).

                           1.2 Features
                                   s Very low on-state resistance                        s Q101 compliant
                                   s 175
