Image preview - the first page of the document
hn1a02f_071122


>> Download hn1a02f_071122 documenatation <<

Text preview - extract from the document
                                                                                                                 HN1A02F
                              TOSHIBA Transistor Silicon PNP Epitaxial Type (PCT Process)


                                               HN1A02F
Audio Frequency Power Amplifier Applications                                                                             Unit: mm

Switching applications
  High hFE : hFE(1) = 120~400
  Low VCE(sat.) : VCE (sat) = -0.2 V (max.) (IC = -400 mA, IB = -8 mA)
  Small Power Motor Driver Application.

Absolute Maximum Ratings (Ta = 25
