hn1b01fu_071101


>> Download hn1b01fu_071101 documenatation <<

Text preview - extract from the document
                                                                                                HN1B01FU
TOSHIBA Transistor Silicon PNP Epitaxial Type (PCT Process) Silicon NPN Epitaxial Type (PCT Process)


                                         HN1B01FU
Audio Frequency General Purpose Amplifier Applications
                                                                                                     Unit in mm

Q1:
  High voltage and high current
             : VCEO = -50V, IC = -150mA (max)
  High hFE : hFE = 120~400
  Excellent hFE linearity
             : hFE (IC = -0.1mA) / hFE (IC = -2mA) = 0.95 (typ.)



Q2:
  High voltage and high current
             : VCEO = 50V, IC = 150mA (max)
  High hFE : hFE = 120~400
  Excellent hFE linearity
             : hFE (IC = 0.1mA) / hFE (IC = 2mA) = 0.95 (typ.)




                                                                           JEDEC
                                                                           JEITA
                                                                           TOSHIBA               2-2J1A
                                                                           Weight: 6.8 mg (typ.)




Q1 Absolute Maximum Ratings (Ta = 25
