Image preview - the first page of the document



>> Download rn1901_rn1906_100514 documenatation <<

Text preview - extract from the document

                                                                                                       RN1901~RN1906
  TOSHIBA Transistor            Silicon NPN Epitaxial Type (PCT Process) (Bias Resistor built-in Transistor)

                                        RN1901,RN1902,RN1903
                                        RN1904,RN1905,RN1906
                                                                                                                      Unit: mm
Switching, Inverter Circuit, Interface Circuit
and Driver Circuit Applications


  Including two devices in US6 (ultra super mini type with 6 leads)
  With built-in bias resistors
  Simplify circuit design
  Reduce a quantity of parts and manufacturing process
  Complementary to RN2901 to RN2906


Equivalent Circuit and Bias Resistor Values


                                           Type No.     R1 (k)        R2 (k)

                                            RN1901       4.7              4.7
                                            RN1902        10              10
                                            RN1903        22              22                  US6
                                            RN1904        47              47                 JEDEC
                                                                                             JEITA
                                            RN1905       2.2              47
                                                                                             TOSHIBA             2-2J1A
                                            RN1906       4.7              47                 Weight: 6.8mg(typ.)


                                                                                          Equivalent Circuit (Top View)


Absolute Maximum Ratings (Ta = 25
