Image preview - the first page of the document
>> Download rn1967-rn1969 documenatation <<
Text preview - extract from the document
RN1967~RN1969
TOSHIBA Transistor Silicon NPN Epitaxial Type (PCT Process)
RN1967,RN1968,RN1969
Unit:mm
Switching, Inverter Circuit, Interface Circuit
And Driver Circuit Applications
l Including two devices in US6 (ultra super mini type 6 leads)
l With built-in bias resistors
l Simplify circuit design
l Reduce a quantity of parts and manufacturing process
l Complementary to RN2967~RN2969
Equivalent Circuit and Bias Resistor Values
Type No. R1 (k) R2 (k)
RN1967 10 47
RN1968 22 47
RN1969 47 22
JEDEC
EIAJ
TOSHIBA 2-2J1B
Weight: 6.8mg
Equivalent Circuit (Top View)
