Image preview - the first page of the document



>> Download rn2901_rn2906_100709 documenatation <<

Text preview - extract from the document

                                                                                                     RN2901~RN2906
   TOSHIBA Transistor Silicon PNP Epitaxial Type (PCT Process) (Bias Resistor Built-in Transistor)

                     RN2901,RN2902,RN2903,RN2904,RN2905,RN2906
Switching, Inverter Circuit, Interface Circuit
and Driver Circuit Applications
                                                                                                                  Unit : mm



   Including two devices in US6 (ultra super mini type with 6 leads)
   With built-in bias resistors
   Simplify circuit design
   Reduce a quantity of parts and manufacturing process
   Complementary to RN1901 to RN1906




Equivalent Circuit and Bias Resistor Values

                                           Type No.    R1 (k)        R2 (k)

                                           RN2901       4.7           4.7
                                           RN2902        10            10
                                           RN2903        22            22
                                                                                            US6
                                           RN2904        47            47
                                           RN2905       2.2            47               JEDEC
                                           RN2906       4.7            47               JEITA
                                                                                        TOSHIBA               2-2J1A
                                                                                        Weight: 6.8 mg (typ.)




Absolute Maximum Ratings (Ta = 25
