Image preview - the first page of the document



>> Download rn2907_rn2909_071101 documenatation <<

Text preview - extract from the document

                                                                                   RN2907~RN2909
                     TOSHIBA Transistor Silicon PNP Epitaxial Type (PCT Process)


                  RN2907,RN2908,RN2909
Switching, Inverter Circuit, Interface Circuit                                                   Unit in mm
And Driver Circuit Applications



  Including two devices in US6 (ultra super mini type with 6 leads)
  With built-in bias resistors
  Simplify circuit design
  Reduce a quantity of parts and manufacturing process
  Complementary to RN1907~1909




Equivalent Circuit and Bias Resistor Values



                                 Type No.   R1 (k)    R2 (k)
                                                                         JEDEC
                                 RN2907       10         47              JEITA
                                                                         TOSHIBA              2-2J1A
                                 RN2908       22         47
                                                                         Weight: 6.8 mg(typ.)
                                 RN2909       47         22




                                                                      Equivalent Circuit (Top View)




                                                       1                                       2007-11-01
                                                                                                                RN2907~RN2909
Absolute Maximum Ratings (Ta = 25
