Image preview - the first page of the document



>> Download 2009115193524527 documenatation <<

Text preview - extract from the document

                                Shenzhen Capsun Electronic Co.,LTD
                Tel0755-33675265                   1882023686920                                           Fax0755-33675266

                                               SPECIFICATION
  SW5     Load life: at 105 2000 hours assured

                Features: Vertical chip type miniaturized for 5mm,high capacitors
                          Suitable for electronic equipment with medium high voltage circuits
                          Rohs compliance
  Main Technology Perfomance
                Item                                                          Characteristice
     Operating temperature
                                                                               -40~105
           range()
     Rated voltage range(V)                                                     4V50V.DC
   Capacitance tolerance(%)
