Image preview - the first page of the document



>> Download 20091151933348890 documenatation <<

Text preview - extract from the document

                                Shenzhen Capsun Electronic Co.,LTD
                Tel0755-33675265                    1882023686920                                                          Fax0755-33675266

                                                   SPECIFICATION
  SWR       Load life: at 105 2000 hours assured
       Features: suitable for high reliability products
      RoHs compliance
  Main Technology Perfomance
                Item                                                                  Characteristice
     Operating temperature
                                                     -40~105                                                             -25~105
           range()
     Rated voltage range(V)                         6.3V100V.DC                                                       160V500V.DC
   Normal Capacit(uF)                                     0.1~10000                                                         0.47~220
   Capacitance tolerance(%)
