Image preview - the first page of the document
>> Download EHL (EHL_070706) documenatation <<Text preview - extract from the document EHL SERIES
105 5000 hours assured life.
Directly mountable on printed circuit board without holders.
Low ESR and long life.
Terminal spacing fixed at 10mm for PC board plug in.
Aluminum case designed explosionproof vent.
Characteristics
Voltage Range 10 ~ 100V 160 ~ 400V
Capacitance Range 560 ~ 47000uF 68 ~ 1500uF
Temperature Range -40 ~ +105 -25 ~ +105
Capacitance Tolerance
