Image preview - the first page of the document
ERS (ERS_110524)


>> Download ERS (ERS_110524) documenatation <<

Text preview - extract from the document
                                                                                                                 ERS SERIES
Features
     Ultra low ESR level and excellent performance at high frequency through low profile.
     Ideal capacitor for digital and high frequency devices.
     High heat resistance and high reliability.

Characteristics
Voltage Range                               2.5 ~50VDC
Capacitance Range                           6.8uF ~ 1500uF
Temperature Range                           -55 ~ +105
Capacitance Tolerance                       M:
