Image preview - the first page of the document
EVS (EVS_110527)


>> Download EVS (EVS_110527) documenatation <<

Text preview - extract from the document
                                                                                                       EVS SERIES
Features
     SMD TYPE. Conductive Polymer Aluminum Solid Capacitors
     This type has lowest ESR level and excellent performance at high frequency through low profile.
     Ideal capacitor for digital and high frequency devices.
Characteristics
Voltage Range                            2.5 ~35VDC
Capacitance Range                        6.8uF ~ 1500uF
Temperature Range                        -55 ~ +105
                                                                             0
Capacitance Tolerance                    M=+20%/-20% , K=+10%/-10% (at 20 C , 120Hz)
Leakage Current                          Capacitance(F) x Rated Voltage(Vdc) After 2minutes, see standard rating
Dissipation Factor ( tan) 20 120Hz See standard rating
ESR ( at 100K~300K Hz, 20 )              See standard rating
Endurance                                Appearance                         No significant damage
(Rated Voltage at 105 2000h, restored to Capacitance Change (F)             Within
