Image preview - the first page of the document
lh


>> Download lh documenatation <<

Text preview - extract from the document
ALUMINUM ELECTROLYTIC CAPACITOR (CD294 LH)
LH FEATURES
      General purpose with snap - in terminal series
      Top safety vent construction
      Ideally suited for switching power supplies, telecommunication and other electronic products

SPECIFICATIONS
                  Item                                                                  Performance Characteristics

    Rated Working Voltage Range                10V.DC~100V.DC                                                        160V.DC~450V.DC
    Operating Temperature Range                   -40
