Image preview - the first page of the document



>> Download sc documenatation <<

Text preview - extract from the document

  ALUMINUM ELECTROLYTIC CAPACITORS
SC         series
FEATURES

  105 Electrolytic Capacitors with Safety Measures
SPECIFICATIONS

         Item                                               Performance Characteristics
 Operating Temperature
        Range                                                           -25~ +105

Rated Voltage Range                                                   160V ~ 500 W.V.
 Capacitance Range                                                       3.3~180uF
Capacitance Tolerance
