Image preview - the first page of the document
>> Download CDF FARADSERIES documenatation <<
Text preview - extract from the document
ALUMINUM ELECTROLYTIC CAPACITORS
CDF FARAD Series
l Our CDF series, which are so-called "Global Capacitance" are "Faraday-grade" capacitors. This series has
filled the emptiness of the nation in "Faraday-grade" aluminum electrolytic capacitors. They have the
characteristics of HIGH CV, LOW ESR. And good performances. These enhance the capability of energy-
storage & ripple-filtering, and also eliminating the interference caused by low frequency. Thus help to solve the
problem, of distortion and arrive at the boundary of "highest-grade music" when used in high-end audio
amplifiers. These products are also widely used in auto-seller machines, sophisticated testing equipment, all
sorts of industrial machines, robots and other high-tech & low voltage DC or pulse circuits
CR(F)
1.5 1.0 0.50 0.25
CR(V)
16 76x220 76x220 76x140 76x90
20 -------- 76x220 76x140 76x90
Characteristics:
Operating Temp. Range -40 ~ +85 deg. C
Rated Working Voltage UR 16 ~ 20V DC
Capacitance Range CR 0.25 ~ 1.5F (+20deg. C, 100 or 120Hz)
Capacitance Tol. C/CR +20% (+20deg. C, 100 or 120Hz)
+20deg. C 100 or 120Hz
CR(F) tg
Z(m) IR(A rms)
UR(V) +20OC +20OC O
+20 C, 100Hz +85OC, 100Hz
100 or 120Hz 100 or 120Hz
Dissipation Factor 0.25 <=0.80 <=8.2 15.2
Impedance Ripple Current 0.5 <=1.20 <=5.1 22.3
16
1.0 <=1.50 <=2.9 31
1.5 <=2.0 <=2.4 37.5
0.25 <=0.70 <=7.8 16.3
20 0.50 <=1.10 <=4.7 23.4
1.0 <=1.40 <=2.7 33.4
<=3 CR UR (mA)
Leakage Current IL
Measured after 2 minutes application of UR at 20O C
Temp. Property (Impe.Rate) Z-40C / Z+20C <= 12(100Hz)
Others Q/SZY002-1998
PRO-AN ELECTRONIC CO., LTD. E-mail: [email protected] Http://www.proan.com.hk
