Image preview - the first page of the document
>> Download SES and SEL Seris_V03_04-28-2006 documenatation <<
Text preview - extract from the document
OP CON Solid Aluminum Capacitor SES & SEL Series
Skywell`s OP-CON is aluminum solid electrolytic capacitor that uses organic semiconductors as electrolytes.
Organic semiconductor has a high conductivity and high-temperature stability, therefore OP-CON has an excellent
performance and high reliability. The constructions of OP-CON are roughly the same as an aluminum electrolytic
capacitor.
CROSS-SECTION CONSTRUCTION
-Material Comparison of OP-Con & Conventional Aluminum Capacitors
Type Aluminum Electrolytic Capacitor OP-CON
Element Construction Forming foil, separator, lead wire Forming foil, separator, lead wire
Dielectric material AL2O3 AL2O3
Electrolyte Electrolytic solution, conductivity, 3mS/cm Organic semiconductor or Conductivity Polymer
Encapsulation Rubber Epoxy resin or Rubber
FEATURES
Low ESR at high frequency (100KHz ~ 1MHz)
Excellent of Noise & Ripple removal capability
Excellent of temperature characteristics (ESR is not dependant on temperature -55~+105)
Long-life up to 10000 hours
APPLICATIONS
Smoothing circuitry of power supply for DC/DC converters
IC power line noise filter for D/A, A/D converters, TTL & CPUs
Digital & analog circuitry for audio & video applications
Replace with large size capacitors on the circuit boards
USA CHINA TAIWAN
www.skywellnet.com 1
OP CON Solid Aluminum Capacitor SES & SEL Series
PART NUMBER SYSTEM
Skywell OP-Con capacitor can be ordered by Skywell part number as follows, such as SEL06T101
SEL 06 T 101
Type Voltage Tolerance Capacitance Option
SES=Standard Type 04=4.0v T=+50-10% 3-digit code 1 or 2 digits
SEL=Low ESR Type 06=6.3v M=+-20% (here is 100uF) P=Polymer
10=10v K=+-10% S=Special size
16=16v C=Lead cut
20=20v PS=Polymer and Special size
25=25v SC=Special size and Lead cut
105, 2000hrs
High ripple current
SES Standard
Low impedance at high frequency.
Suitable for switching power supplies , noise filter
Items Performance requirements
Operation temperature range -55~105
Rated working voltage range 6.3~25V. DC
Nominal capacitance range 2.2uF~330uF
Capacitance tolerance ◦ Jabse Service Manual Search 2025 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
