                     CONDUCTIVE POLYMER ALUMINUM SOLID CAPACITORS
                     8 mm height & Ultra low ESR
CP                   Series

 Features: 105,3000hrs, 8mm height & Ultra Low ESR
 Recommended Applications: Motherboard, DC/DC Converter ,
                            Adapter , SPS ,VCR , camcorder , DSC , PDA,
                            HD Drive , MO Drive , DVD Drive, Navigation system,
                            Portable Communication Devices
 Corresponding product to RoHS

 Specifications
               Item                                                           Characteristics
Category Temperature Range           -55 ~ +105
Rated Voltage Range                 2.5 ~ 25VDC
Rated Capacitance Range             10 ~ 1200 F
Capacitance Tolerance
