Image preview - the first page of the document



>> Download cv documenatation <<

Text preview - extract from the document

                        SURFACE MOUNT ALUMINUM ELECTROLYTIC

CV            Low Leakage
              Series

Features : 85 2000 hours , Low profile vertical chip,
           Low Leakage current ( 0.5A to 2.0A max.)
Recommended Applications: Security System , Backup Battery
Corresponding product to RoHS

 Specifications
             Item                                                       Characteristics
Operating Temperature Range     -40 ~ +85
Rated Voltage Range (WV)        6.3 ~ 50VDC
Capacitance Range               0.1 ~ 100F
Capacitance Tolerance
