Image preview - the first page of the document



>> Download cx documenatation <<

Text preview - extract from the document

                  CONDUCTIVE POLYMER ALUMINUM SOLID CAPACITORS

CX                Large capacitance
                  Series

 Features: 105,2000hrs, Low ESR & large capacitance
 Recommended Applications: Used switching requlator applications in computer.
Especially for high frequency.



 Specifications
               Item                                                         Characteristics
Category Temperature Range          -55 ~ +105
Rated Voltage Range                2.5 ~28VDC
Rated Capacitance Range            33 ~ 820 F
Capacitance Tolerance
