Image preview - the first page of the document

>> Download jv documenatation <<

Text preview - extract from the document

 JV          Ultra Low Impedance

Features : 105 2000 hours , Low profile vertical chip, Ultra low impedance
Recommended Applications: AV(TV,Video,Audio) ,Monitor/Computer,
                                OA/HA/Communication ,SMPS
Corresponding product to RoHS

             Item                                                       Characteristics
Operating Temperature Range     -40 ~ +105
Rated Voltage Range (WV)        6.3 ~ 35VDC
Capacitance Range               10~ 1800F
Capacitance Tolerance
