Image preview - the first page of the document
sv


>> Download sv documenatation <<

Text preview - extract from the document
                           SURFACE MOUNT ALUMINUM ELECTROLYTIC

SV           General Purpose
             Series

Features : 105 1000 hours , Higher temperature range Than GV, Low profile vertical chip
Recommended Applications: Suitable for AV(TV,Video,Audio),Monitor/Computer,
                           OA/HA/Communication
Corresponding product to RoHS

 Specifications
             Item                                                           Characteristics
Operating Temperature Range              -40 ~ +105
Rated Voltage Range (WV)                 4 ~ 100VDC
Capacitance Range                       0.1 ~ 1500F
Capacitance Tolerance
