Image preview - the first page of the document
>> Download 8cj documenatation <<
Text preview - extract from the document
BOR HURNG ELECTRONIC CO., LTD.
ALUMINIUM ELECTROLYTIC CAPACITORS
LEAD FORMING & CUTTING SPECIFICATION
C
CUTTING FORMING & CUTTINGFC
D 4 5 6.3 8
D 4 5 6.3 8 10 13 16 18 22
d 0.45 0.5
d 0.45 0.5 0.6 0.8 0.8 8
F 5.0
F 1.5 2.0 2.5 3.5 5.0 7.5 10 P 1.5 2.0 2.5 3.5
KINK FORMINGK KINK FORMINGY
D 4 5 6.3 8 D 10 13 16 18
d 0.45 0.5 0.5 0.5 d 0.6 0.6 0.8 0.8
F 5.0 5.0 5.0 5.0 F 5.0 5.0 7.5 7.5
P 1.5 2.0 2.5 3.5 f 1.3 1.3 1.3 1.3
f 1.3 1.3 1.3 1.3
