Image preview - the first page of the document
>> Download General Catalogue documenatation <<
Text preview - extract from the document
BOR HURNG ELECTRONIC CO., LTD.
PRODUCT CATALOGUE
Temperature Voltage Capacitance
Category Series Type Features Applications
Range() Range (V) Range (F)
special design for
105, high ripple current resistant,
PSL radial
10,000 hours extremely long life
electronic ballast and -40+105 200450 1220
energy saving lamp
special design for
Energy 105, high ripple current resistant,
PST radial
8,000 hours extremely long life
electronic ballast and -40+105 200450 1220
energy saving lamp
Saving
Lamp
special design for
105, high ripple current resistant,
Specialties
PSH radial
5,000 hours extremely long life
electronic ballast and -40+105 200450 1220
energy saving lamp
special design for
105, high ripple current resistant,
PSA radial
3,000 hours long life
electronic ballast and -40+105 200450 1220
energy saving lamp
general power supply
TRM snap-in 85, snap-in standard
filtering
-40+85 10450 4782000
Large
switching power supply
TRR snap-in 105, snap-in wide temperature
filtering
-40+105 10450 4768000
SS radial 5mm high, standard high density circuits -40+85 450 0.1220
high density and high
SR radial 5mm high, wide temperature
temperature circuits
-40+105 450 0.1220
Supper
Miniature
SSM radial 7mm high, standard high density circuits -40+85 6.363 0.1470
high density and high
SSR radial 7mm high, wide temperature
temperature circuits
-40+105 6.363 0.1330
SM radial 85, standard general purpose -40+85 6.3450 0.110000
SMR radial 105, wide temperature high temperature circuits -40+105 6.3450 0.110000
Miniature
LL radial low leakage current low signal circuits -40+85 6.3100 0.110000
switching power supply
PSR radial high frequency, low ESR
filtering, stereo system
-40+105 6.3100 4.710000
NP radial non-polarized, standard polarity reversal circuits -40+85 6.3100 0.16800
