Image preview - the first page of the document



>> Download PLH documenatation <<

Text preview - extract from the document

                                  BOR HURNG ELECTRONIC CO., LTD.
                                                                                                                     SERIES: PLH
                                   ALUMINIUM ELECTROLYTIC CAPACITORS

FEATURES
 105, radial lead type, high temperature resistant
 5,000 - 7,000 hours long life
 Suited for LED light and other higher temperature environment requirements

SPECIFICATION
   S
       Item                                                         Key Features
  Operating
 Temperature                       -40+105                                                        -25+105
    Range
    Rated
   Working
   Voltage                       6.3VDC100VDC                                                   160VDC450VDC
    Range
   Nominal
 Capacitance                      0.1uF10,000uF                                                   0.47uF470uF
    Range
 Capacitance
  Tolerance
