BOR HURNG ELECTRONIC CO., LTD.
ALUMINIUM ELECTROLYTIC CAPACITOR
PROCESS & QUALITY CONTROL FLOW CHART
LEAD TAPING SPECIFICATION
Material Flow Chart
Anode Foil
Cutting
Cathode Foil
Lead Wire Stitching
Paper Winding
Electrolyte Impregnation
Rubber
Assembly
Automatic assembling machine
Aluminum Case
Sealing
40
cleaning
Sleeve Insertion
Automatic Agening Sorting Machine
On-Shelf
Aging
Sorting
Inspection
Paper
Taping Cutting
Tape
Packing Material Packing
Warehouse
OQC
DESCRIPTION OF SYMBOLS
DEPT MATERIAL INSPECTION (IQC) QC AUDITION (IPQC) (FQC)
